FPX 564 TRV Gas Fireplace Series
The 564 Series gas fireplaces are perfect for heating individual rooms in the home — bedrooms, home offices, and family rooms. The shallow firebox design takes up less space, making installation flexible in almost any room. All 564 models feature large ceramic glass viewing areas and are available with top or rear venting (TRV).
Choose the model that best fits your heating needs and style preference:
Model Comparison
| Model | BTU Output | Face Style | Key Features |
|---|---|---|---|
| 564 TRV 25K Deluxe | 25,000 BTU | Designer face | Ember-Glo™ ember bed lighting, adjustable overhead accent lights, Classic Oak or Birch log sets, optional CoolSmart TV Wall™ |
| 564 TRV 25K Clean Face | 25,000 BTU | Clean face (no grills or facing) | Same features as 25K Deluxe with a clean-face look |
| 564 TV 35K Deluxe | 35,000 BTU | Designer face | Significantly increased heating capacity with same compact footprint and installation flexibility |
| 564 TV 35K Clean Face | 35,000 BTU | Clean face (no grills or facing) | Same features as 35K Deluxe with a clean-face look |
25K Model Specifications
| Heating Capacity | Up to 1,250 sq. ft. |
| BTU Input Range | 7,500 (NG) / 6,500 (LP) – 25,000 (NG/LP) |
| Steady State Efficiency | Up to 79.67% (NG) / 80.16% (LP) |
| EnerGuide P4 Efficiency | 70.28% (NG) / 71.10% (LP) |
| Glass Viewing Area | Tempered Glass — 29-3/8″ W × 16-3/8″ H (479.8 sq. in.) |
35K Model Specifications
| Heating Capacity | Up to 1,700 sq. ft. |
| BTU Input Range | 7,500 (NG) / 12,000 (LP) – 35,000 (NG/LP) |
| Steady State Efficiency | Up to 82.77% (NG) / 84.36% (LP) |
| EnerGuide P4 Efficiency | 75.07% (NG) / 75.80% (LP) |
| Glass Viewing Area | Ceramic Glass — 29-3/8″ W × 16-3/8″ H (481 sq. in.) |
All Models Include
| Venting | Top or Rear (TRV) |
| Ember Lighting | Ember-Glo™ ember bed + adjustable overhead accent lights |
| Log Sets | Classic Oak or Birch (choice) |
| Optional | CoolSmart TV Wall™ |
Contact us for pricing and availability. Visit our showroom or call (360) 336-2532 to speak with our team.
